lightweight mgo hollow core wall panel machine for house

FOB Reference Price:Get Latest Price
$30,000.00 - $450,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Automatic
Place of Origin:
Shandong, China
Voltage:
380V/50HZ
Dimension(L*W*H):
2440*610mm
Features:
Easy Operation
Certification:
ISO9001
Item:
lightweight mgo hollow core wall panel machine for house
Thickness:
40-200mm
Advantages:
hollow core panel; sandwich panel; solid core panel
Automatic:
Full/semi automatic
Capacity:
20000-500,000sqm/year
Length:
2400-3000mm
Performance:
waterproof; heat insulation; fireproof; anti-earthquake, etc
Raw material:
EPS foam; cement; fly ash; calcium silicate board/mgo board, etc
Installation& commissioning:
Engineer assigned
Width:
610mm
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
80 Set/Sets per Year
Packaging & Delivery
Packaging Details
Standard package suited for shipping transportation;
We use pallet; box to protect every part.
We mark every part with your required label.
Port
Qingdao
Lead Time :
1-3months, according to your capacity and required configuration
Video Description
Product Description
EPS lightweight panel making production line mainly has the following parts.
Foaming system, storage system, automatic conveying system, automatic measuring system, mixing system, pumping and pouring system, panel forming system and operating system


Finished board Type

3D wall panel


3D wall panel is a kind of new type architecture wall material. It can replace the brisk wall to be kinds of main wall, non-main wall, and boundary etc. 3D mesh is a three-dimensional mesh, this product is widely used in Europe and the United States in the construction system to replace the wood framework wall, metal or prefabricated plate, has a flexible structure, simple construction, improve efficiency, save labor characteristics. Park wall arch corners, curved wall using this product with camber free construction simply and quickly, modeling beautiful and so on as their characteristics

Machine parameters


Main parts

Mixing platform



We adopt double-shaft mixer, which has compact structure, beautiful appearance, stable running, convenient operation, high production efficiency.
There is vibrator on the mixer so as to make the materials without blocking.



Horizontal mold car
1)Capacity:  horizontal capacity is relatively low than vertical   mold car
2)Operation:  the horizontal mold car it's easy for operation,      and the worker is more safety.
3)Finished board type: sandwich panel, solid panel, and              hollow core panel.
4)Different holes requirement just need to change different        mold

Name: Pumping system

Used to paste into the mold, can avoid the air holes.


The feeding machine can be movable, or fixed, matched well with the mold car, easily operate



Full automatic turnover; Demolding; stacking system

Turn over the mold car → pull out the panels automatically, largest advatage is it could pull out 40 panels at one time →turn over the board make it horizontally→use the seperate machine to seperate the board

Packing & Delivery


We will design eps wall panel production line loading qty many times, so as to save your sea freight

1.Firstly use plastic film to wrap and cover the machine;
2.Then pack small parts in plywood box.
3.Marked with required label or shipping mark.
4.Use steel wire rope to fix in the container, so as to avoid damage because of moving

Our Service

1. Full life-cycle value services: Our company provides production line design, cost accounting, installation and operation, equipment maintenance and the whole life cycle technical support

2. All-around technical service: we provide technical formula for clients, to help clients to occupy the leading position in the market.

3.Complete data specification: Provide production line equipment technical data and instructions, and provide the formula.

4. Quality commitment: The company regards product quality as the lives of enterprises, the main components and wearing parts are made of high quality wear-resistant materials and advanced processing technology, so that the equipment endurable and wear resisting, wearing parts warranty for one year, and our company perennial supply of device of wearing parts.

5.Trade Service: We can help the customer to do the consignment and the relevant procedure for import and export

FAQ
Q:
Do you supply spare parts?
A:
Excellent easy broken parts support for buyers. Easy broken parts guarantee for one year.
Q:
Will you provide trainning?
A:
The training is free of charge , and our engineer will be on duty to train your worker.
Q:
How will you provide installation&commissioning?
A:
Will send 2~4engineers (adjustable according to the degree of automatic )to installall and testing the whole line for you
Q:
How long is the delivery time?
A:
Generally 45-90working days for one set. But it differs from configuration and our schedule.
Q:
How much land do I need?
A:
It is differet from capacity and configuration. If you have land, can send to me, we will design layout for you.
